SUP-P300G High temperature pressure transmitter
Applications: SUP-P300 is a piezoresistive pressure sensor with compact design and stainless steel body SS304 and SS316L diaphragm , can work in the non-causticity environment, with 4-20mA signal output.
- Description
Description
Specification
| Product | Pressure transmitter |
| Model | SUP-P300G |
| Measure range | -0.1~0 to 0 ~ 40MPa |
| Indication resolution | 0.5% |
| Medium temperature | -50-300°C |
| Working temperature | -40-85°C |
| Output signal | 4-20ma analog output |
| Pressure type | Gauge pressure; Absolute pressure |
| Measure medium | Liquid; Gas; Oil etc |
| Pressure overload | 150%FS |
| Power | DC24 (12-36V) |
Introduction
SUP-P300G High temperature pressure transmitter
